Specifications - bizhub C368/C308/C258

Specification

General Specifications bizhub C368

General Specifications bizhub C368
Type		Desktop full colour printer / Copier / Scanner
Colour support		Full colour
Copy resolution	Scan	Main: 600 dpi × Sub: 600 dpi
Copy resolution	Print	1,800 dpi (equivalent) × 600 dpi
Gradation		256
Memory capacity (Std./Max.)		2 GB/4 GB
HDD		250 GB
Original type		Sheets, Books, Objects
Max. original size		A3 (11" × 17")
Output size		Main unit: SRA3¹, A3 to A5, 12-1/4" × 18" (A3 wide (311.1 mm × 457.2 mm)), 11" × 17" to 8-1/2" × 11", 5-1/2" × 8-1/2", 8" × 13"², 16K, 8K Bypass Tray: SRA3, A3 to A5, B6³, A6³, 12" × 18" (A3 wide (311.1 mm × 457.2 mm)), 11" × 17" to 5-1/2" × 8-1/2", 8" × 13" ⁴, 16K, 8K, Postcard (A6 (4" × 6" Card)), Envelope⁵, Label sheet, Tab paper, Banner paper (Width: 210 mm to 297 mm (8-1/4" to 11-11/16"), Length: 457 mm to 1,200 mm (18" to 47-1/4"))*⁶
Image loss		Max. 4.2mm or less for top edge (5 mm for thin paper), Max. 3.0mm or less for bottom edge, Max. 3.0mm or less for right/left edges *A loss of 4.2 mm each during printing.
Warm-Up Time⁷ (23°C, std. voltage) The time required to start printing when both the main power and sub-power switches are turned from OFF to ON.		Colour/B&W: 20 sec. or less
* The time required to star t printing when the main power switch is ON and the sub-power switch is turned from OFF to ON.		Colour/B&W: 20 sec. or less
Copy out time*⁸	Colour	6.9 sec. or less
Copy out time*⁸	B/W	5.3 sec. or less
Copy speed (Colour/B&W, A4)		36 ppm
Copy magnification	Fixed Same magnification	1: 1±0.5% or less
	Scaling up	1: 1.154/1.224/1.414/2.000
	Scaling down	1: 0.866/0.816/0.707/0.500
	Preset	3 types
	Zoom	25 to 400% (in 0.1% increments)
	Lengthwise crosswise individual settings	25 to 400% (in 0.1% increments)
Paper capacity (80 g/m²)	Tray 1	500 sheets (up to B4)
	Tray 2	500 sheets (up to A3)
	Multiple Bypass Tray	150 sheets (up to SRA3)
Max. paper capacity (80 g/m²)*⁹		6,650 sheets
Paper weight	Tray 1	52 to 256 g/m²
Paper weight	Multiple Bypass Tray	60 to 300 g/m²
Multiple copy		1 to 9,999 sheets
Auto duplex	Paper size	SRA3, A3 to A5, B6³, A6³, 12-1/4" × 18" (A3 wide (311.1 mm × 457.2 mm)), 11" × 17"³ to 5-1/2" × 8-1/2"³, 7-1/4" × 10-1/2", 8" × 13", 16K, 8K, Postcard (A6 (4" × 6" Card))
Auto duplex	Paper weight	52 to 256 g/m²
Power requirements		AC220 to 240 V 8.0 A (50/60 Hz)
Max. power consumption		1.5 kW or less
Dimensions [W] × [D] × [H]		615 × 685 × 779 mm (24-3/16" × 27-15/16" × 30-11/16")
Weight		Approx. 85 kg (187-3/8 lb)
Space requirements [W] × [D]*¹⁰		937 × 1,214 mm (36-7/8" × 47-13/16")

*1 SRA3 paper can be used in Tray2.
*2 There are four types of foolscap: 8-1/2" × 13-1/2"*2, 8-1/2" × 13"*2, 8-1/4" × 13"*2, and 8" × 13"*2.
Any one of these sizes is selectable. For details, contact your service representative.
*3 Short edge feed

*4 There are six types of foolscap: 8-1/2" × 13-1/2"*3, 220 mm × 330 mm*3, 8-1/2" × 13"*3, 8-1/4" × 13"*3, 8-1/8" × 13-1/4"*3, and 8" × 13"*3.
Any one of these sizes is selectable. For details, contact your service representative.
*5 Wrinkles or printing errors may occur due to the type, storage or environment that exists when envelope printing is carried out.
*6 Printing on banner paper can only be performed from a PC.
*7 May vary depending on the operating environment and usage.
*8 A4 long edge feed full size/using the first tray/scanning from the original glass surface.
*9 With options installed.
*10 Without options, with paper trays pulled out, and multiple bypass tray, auxiliary tray and ADF opened.

Back to Top

General Specifications bizhub C308

General Specifications bizhub C308
Type		Desktop full colour printer / Copier / Scanner
Colour support		Full colour
Copy resolution	Scan	Main: 600 dpi × Sub: 600 dpi
Copy resolution	Print	1,800 dpi (equivalent) × 600 dpi
Gradation		256
Memory capacity (Std./Max.)		2 GB/4 GB
HDD		250 GB
Original type		Sheets, Books, Objects
Max. original size		A3 (11" × 17")
Output size		Main unit: SRA3¹, A3 to A5, 12-1/4" × 18" (A3 wide (311.1 mm × 457.2 mm)), 11" × 17" to 8-1/2" × 11", 5-1/2" × 8-1/2", 8" × 13"², 16K, 8K Bypass Tray: SRA3, A3 to A5, B6³, A6³, 12" × 18" (A3 wide (311.1 mm × 457.2 mm)), 11" × 17" to 5-1/2" × 8-1/2", 8" × 13" ⁴, 16K, 8K, Postcard (A6 (4" × 6" Card)), Envelope⁵, Label sheet, Tab paper, Banner paper (Width: 210 mm to 297 mm (8-1/4" to 11-11/16"), Length: 457 mm to 1,200 mm (18" to 47-1/4"))*⁶
Image loss		Max. 4.2mm or less for top edge (5 mm for thin paper), Max. 3.0mm or less for bottom edge, Max. 3.0mm or less for right/left edges *A loss of 4.2 mm each during printing.
Warm-up time⁷ (23°C, std. voltage) The time required to start printing when both the main power and sub-power switches are turned from OFF to ON.		Colour/B&W: 20 sec. or less
* The time required to star t printing when the main power switch is ON and the sub-power switch is turned from OFF to ON.		Colour/B&W: 18 sec. or less
Copy out time*⁸	Colour	7.3 sec. or less
Copy out time*⁸	B/W	5.6 sec. or less
Copy speed (Colour/B&W, A4)		30 ppm
Copy magnification	Fixed same magnification	1: 1±0.5% or less
	Scaling up	1: 1.154/1.224/1.414/2.000
	Scaling down	1: 0.866/0.816/0.707/0.500
	Preset	3 types
	Zoom	25 to 400% (in 0.1% increments)
	Lengthwise crosswise individual settings	25 to 400% (in 0.1% increments)
Paper capacity (80 g/m²)	Tray 1	500 sheets (up to B4)
	Tray 2	500 sheets (up to A3)
	Multiple Bypass Tray	150 sheets (up to SRA3)
Max. paper capacity (80 g/m²)*⁹		6,650 sheets
Paper weight	Tray 1	52 to 256 g/m²
Paper weight	Multiple Bypass Tray	60 to 300 g/m²
Multiple copy		1 to 9,999 sheets
Auto duplex	Paper size	SRA3, A3 to A5, B6³, A6³, 12-1/4" × 18" (A3 wide (311.1 mm × 457.2 mm)), 11" × 17"³ to 5-1/2" × 8-1/2"³, 7-1/4" × 10-1/2", 8" × 13", 16K, 8K, Postcard (A6 (4" × 6" Card))
Auto duplex	Paper weight	52 to 256 g/m²
Power requirements		AC220 to 240 V 8.0 A (50/60 Hz)
Max. power consumption		1.5 kW or less
Dimensions [W] × [D] × [H]		615 × 685 × 779 mm (24-3/16" × 27-15/16" × 30-11/16")
Weight		Approx. 85 kg (187-3/8 lb)
Space requirements [W] × [D]*¹⁰		937 × 1,214 mm (36-7/8" × 47-13/16")

*1 SRA3 paper can be used in Tray2.
*2 There are four types of foolscap: 8-1/2" × 13-1/2"*2, 8-1/2" × 13"*2, 8-1/4" × 13"*2, and 8" × 13"*2.
Any one of these sizes is selectable. For details, contact your service representative.
*3 Short edge feed

*4 There are six types of foolscap: 8-1/2" × 13-1/2"*3, 220 mm × 330 mm*3, 8-1/2" × 13"*3, 8-1/4" × 13"*3, 8-1/8" × 13-1/4"*3, and 8" × 13"*3.
Any one of these sizes is selectable. For details, contact your service representative.
*5 Wrinkles or printing errors may occur due to the type, storage or environment that exists when envelope printing is carried out.
*6 Printing on banner paper can only be performed from a PC.
*7 May vary depending on the operating environment and usage.
*8 A4 long edge feed full size/using the first tray/scanning from the original glass surface.
*9 With options installed.
*10 Without options, with paper trays pulled out, and multiple bypass tray, auxiliary tray and ADF opened.

Back to Top

General Specifications bizhub C258

General Specifications bizhub C258
Type		Desktop full colour printer / Copier / Scanner
Colour support		Full colour
Copy resolution	Scan	Main: 600 dpi × Sub: 600 dpi
Copy resolution	Print	1,800 dpi (equivalent) × 600 dpi
Gradation		256
Memory capacity (Std./Max.)		2 GB/4 GB
HDD		250 GB
Original type		Sheets, Books, Objects
Max. original size		A3 (11" × 17")
Output size		Main unit: SRA3¹, A3 to A5, 12-1/4" × 18" (A3 wide (311.1 mm × 457.2 mm)), 11" × 17" to 8-1/2" × 11", 5-1/2" × 8-1/2", 8" × 13"², 16K, 8K Bypass Tray: SRA3, A3 to A5, B6³, A6³, 12" × 18" (A3 wide (311.1 mm × 457.2 mm)), 11" × 17" to 5-1/2" × 8-1/2", 8" × 13" ⁴, 16K, 8K, Postcard (A6 (4" × 6" Card)), Envelope⁵, Label sheet, Tab paper, Banner paper (Width: 210 mm to 297 mm (8-1/4" to 11-11/16"), Length: 457 mm to 1,200 mm (18" to 47-1/4"))*⁶
Image loss		Max. 4.2mm or less for top edge (5 mm for thin paper), Max. 3.0mm or less for bottom edge, Max. 3.0mm or less for right/left edges *A loss of 4.2 mm each during printing.
Warm-up time⁷ (23°C, std. voltage) The time required to start printing when both the main power and sub-power switches are turned from OFF to ON.		Colour/B&W: 20 sec. or less
* The time required to star t printing when the main power switch is ON and the sub-power switch is turned from OFF to ON.		Colour/B&W: 18 sec. or less
Copy out time*⁸	Colour	7.5 sec. or less
Copy out time*⁸	B/W	6.1 sec. or less
Copy speed (Colour/B&W, A4)		25 ppm
Copy magnification	Fixed same magnification	1: 1±0.5% or less
	Scaling up	1: 1.154/1.224/1.414/2.000
	Scaling down	1: 0.866/0.816/0.707/0.500
	Preset	3 types
	Zoom	25 to 400% (in 0.1% increments)
	Lengthwise crosswise individual settings	25 to 400% (in 0.1% increments)
Paper capacity (80 g/m²)	Tray 1	500 sheets (up to B4)
	Tray 2	500 sheets (up to A3)
	Multiple Bypass Tray	150 sheets (up to SRA3)
Max. paper capacity (80 g/m²)*⁹		6,650 sheets
Paper weight	Tray 1	52 to 256 g/m²
Paper weight	Multiple Bypass Tray	60 to 300 g/m²
Multiple copy		1 to 9,999 sheets
Auto duplex	Paper size	SRA3, A3 to A5, B6³, A6³, 12-1/4" × 18" (A3 wide (311.1 mm × 457.2 mm)), 11" × 17"³ to 5-1/2" × 8-1/2"³, 7-1/4" × 10-1/2", 8" × 13", 16K, 8K, Postcard (A6 (4" × 6" Card))
Auto duplex	Paper weight	52 to 256 g/m²
Power requirements		AC220 to 240 V 8.0 A (50/60 Hz)
Max. power consumption		1.5 kW or less
Dimensions [W] × [D] × [H]		615 × 685 × 779 mm (24-3/16" × 27-15/16" × 30-11/16")
Weight		Approx. 85 kg (187-3/8 lb)
Space requirements [W] × [D]*¹⁰		937 × 1,214 mm (36-7/8" × 47-13/16")

*1 SRA3 paper can be used in Tray2.
*2 There are four types of foolscap: 8-1/2" × 13-1/2"*2, 8-1/2" × 13"*2, 8-1/4" × 13"*2, and 8" × 13"*2.
Any one of these sizes is selectable. For details, contact your service representative.
*3 Short edge feed

*4 There are six types of foolscap: 8-1/2" × 13-1/2"*3, 220 mm × 330 mm*3, 8-1/2" × 13"*3, 8-1/4" × 13"*3, 8-1/8" × 13-1/4"*3, and 8" × 13"*3.
Any one of these sizes is selectable. For details, contact your service representative.
*5 Wrinkles or printing errors may occur due to the type, storage or environment that exists when envelope printing is carried out.
*6 Printing on banner paper can only be performed from a PC.
*7 May vary depending on the operating environment and usage.
*8 A4 long edge feed full size/using the first tray/scanning from the original glass surface.
*9 With options installed.
*10 Without options, with paper trays pulled out, and multiple bypass tray, auxiliary tray and ADF opened.

Back to Top

Print Specifications

Print Specifications
Type		Embedded
CPU		ARM Cortex-A7 Dual-core 1.2GHz
Memory		Shared with the copier
Print speed		Same as copy speed (when using the same original)
HDD		250 GB (Shared with the copier)
Print resolution		1,800 dpi (equivalent) × 600 dpi (at smoothing) or 1,200 dpi × 1,200 dpi (in 1,200 dpi mode)
PDL		PCL 6, PostScript 3 Emulation, XPS
Protocol		TCP/IP（LPD, Raw, SMB, IPP), AppleTalk, IPX/SPX
Support OS		Windows Vista¹ / 7¹ / 8.1¹ / 10¹ Windows Server 2008*¹ / 2008 R2 / 2012 / 2012 R2 Mac OS X (10.7 / 10.8 / 10.9 / 10.10 / 10.11) Linux
Fonts	PCL	80 Roman fonts
Fonts	PS	137 Roman Type1 fonts
Interface		Ethernet (10BASE-T/100BASE-TX/1000BASE-T), USB 1.1, USB 2.0, IEEE 802.11 b/g/n*²

*1 Supports the 32-bit (x86) or 64-bit (x64) environment.
*2 Optional

Back to Top

Scanning Specifications

Scanning Specifications
Type		Full-colour scanner
Interface		Ethernet (10BASE-T/100BASE-TX/1000BASE-T), IEEE 802.11 b/g/n*¹
Driver		TWAIN driver, HDD TWAIN driver
Protocol		TCP/IP (FTP, SMB, SMTP, WebDAV) (IPv4/IPv6)
Scanning speed (Colour/B&W) (300 dpi, A4, Simplex)		80 opm*²
Scanning size		Max. A3 (11" × 17")
Output format		TIFF, JPEG, PDF, Compact PDF, XPS, Compact XPS, OOXML (pptx, xlsx¹, docx¹), Searchable PDF¹, PDF/A¹, Linearised PDF*¹
Scanning resolution	Push	200 dpi / 300 dpi / 400 dpi / 600 dpi
Scanning resolution	Pull	100 dpi / 200 dpi / 300 dpi / 400 dpi / 600 dpi
Main functions		Scan to E-Mail, Scan to FTP, Scan to BOX (HDD), Scan to PC (SMB), Network TWAIN, Scan to WebDAV, Scan to USB, Scan to Scan Server, Scan to Web Service (WSD-Scan), Device Profile for Web Services (DPWS)
Other functions		Multi-method send, authentication at the time of e-mail send (SMTP authentication, POP before SMTP), S/MIME, annotation

*1 Optional
*2 When using the Reverse Automatic Document Feeder DF 628.

Back to Top

Internet Fax

Internet Fax
Protocol	TX: SMTP, RX: POP3, TCP/IP Simple mode
Connection mode	Full-mode
Sending paper size	A3, B4, A4
Recording paper size	Max. A3
Resolution	B/W: 200 × 100 dpi, 200 × 200 dpi, 400 × 400 dpi, 600 × 600 dpi Colour: 200 × 200 dpi, 400 × 400 dpi, 600 × 600 dpi
Interface	Ethernet (10BASE-T/100BASE-TX/1000BASE-T)
Colour	Support colour internet fax
Format	B/W: TIFF-F Colour: TIFF (Conforms to RFC3949 Profile-C)

Back to Top

Fax Kit FK-514 (Optional)

Fax Kit FK-514 (Optional)
Communication	Super G3
Compatible lines	Public switch telephone network, Private branch exchange, Fax communication line
Line density	Ultra fine: 600 dpi 600 dpi Super fine: 16 dot/mm 15.4 line/mm, 400 dpi 400 dpi Fine: 8 dot/mm 7.7 line/mm, 200 dpi 200 dpi Normal: 8 dot/mm 3.85 line/mm
Modem speed	2.4 to 33.6 kbps
Compression	MH/MR/MMR/JBIG
Sending paper size	Max. A3 (Long Length Support: Max.1,000 mm)
Recording paper size	Max. A3 (Long Length Max. 1,000 mm — following the page division —)
Transmission speed	Less than 2 sec. (A4, V.34, 33.6 kbps, JBIG)
Memory	Shared with the copier
Number of abbr. dials	2,000
Number of program dials	400
Number of group dials	100
Sequential multiple station transmission	Max. 600

Back to Top

IP Address Fax (Optional) * Optional Fax Kit FK-514 is required.

IP Address Fax (Optional) * Optional Fax Kit FK-514 is required.
Protocol transmission	TCP/IP, SMTP
Sending paper size	A3, B4, A4
Resolution	200 × 200 dpi, 400 × 400 dpi, 600 × 600 dpi
Format	B/W: TIFF-F, TIFF-S Colour: TIFF, PDF

Back to Top

Fiery Image Controller IC-416 (Optional) * Optional Upgrade Kit UK-211 and Video Interface Kit VI-508 is required.

Fiery Image Controller IC-416 (Optional)* Optional Upgrade Kit UK-211 and Video Interface Kit VI-508 is required.
Type	Embedded
CPU	Intel Pentium G850 2.9GHz
Memory	2 GB
HDD	500 GB
Print speed	1,800 dpi (equivalent) × 600 dpi (at smoothing) or 1,200 dpi × 1,200 dpi (in 1,200 dpi mode)
Print resolution	TCP
PDL	Adobe PostScript 3
Protocol	Ethernet (Apple Talk, TCP/IP), HTTP/HTTPS, SSL/TLS for HTTPS, SNMP v3, SMB, Port9100 (Bi-Directional), IPP, LDAP, IPV6
Support OS	Windows Vista¹ / 7¹ / 8.1¹ / 10¹ Windows Server 2008*¹ / 2008 R2 / 2012 Mac OS X (10.7 / 10.8 / 10.9 / 10.10 / 10.11)
Fonts	Adobe PS 138 Roman fonts, Agfa PCL 80 Roman fonts and 1 bitmap font, Additional PCL 35 fonts, Euro Currency Resident Font
Interface	Ethernet (10BASE-T/100BASE-TX/1000BASE-T)

*1 Supports the 32-bit (x86) or 64-bit (x64) environment.
